The material is loaded into the hopper, and the powder is fed into the lower hopper, the movable guide pipe, the metering hopper and the lower hopper, and then into the packaging material that is vertical sealed and horizontal sealed, and then into the upper horizontal seal and completely encapsulated. After the packaging is completed, the finished product output is finished by printing the batch number, vertical cutting and horizontal cutting.
Product with vertical easy tear and horizontal easy tear line.
The whole machine adopts full servo automatic control, and the power is provided by 6 sets of independent servo motors, which are feeding, longitudinal sealing (longitudinal cutting and longitudinal breaking alignment), transverse sealing, typing, transverse cutting and transverse breaking alignment (optional) HMI interface display system control items, system status indicator, system alarm and fault diagnosis system. In addition, it allows the operator to start and stop the program and set its process parameters according to the level of the operator.
The machine can be used for automatic alignment and automatic tracking adjustment. Heating temperature automatic control, packaging materials and other multi-point failure and misoperation automatic protection stop.
The touch screen user interface is adopted, and the operation interface has access level control.
In the design capacity of the single bag and multiple bags at the same time to adjust the amount of packaging, error 5%.
|
Machine Model |
DXDF950 |
|
Capacity [sachets/min] |
240 |
|
Max filling volume [ml] |
Grain:1-120 Power:1-80 Liquid:3-100 |
|
Sachet size [mm] |
W:35-120 L:50-180 |
|
Horizontal cutting [times/min] |
35-40 |
|
Packing lane |
2-12 |
|
Max packing material width [mm] |
950 |
|
Suitable packing material |
PE AL PET |
|
Metering precision |
±5% |
|
Noise [dba] |
65 |
|
Power [kw] |
15 |
|
Power supply |
380V 50Hz 3P |
|
Weight [kg] |
2000 |
|
Dimension [mm] |
2150*2350*2100 |
